Alteration of Cytokine Production during Visceral Larva Migrans by Toxascaris leonina in Mice

Most roundworms, which infect only 1 or 2 specific hosts, live in the intestine of their definitive host, and are generally well adapted to the immune system of their host. Although they can sometimes cause mild allergic responses in their hosts during the larval stage (migration period), after growing into the adult worm they are not likely to cause severe pathological changes in their definitive host [1]. However, when juveniles of several species of nematodes gain entry to an improper host, they begin a typical tissue migration called visceral larva migrans (VLM). They do not complete the normal migration but undergo developmental arrest and begin an extended and random wandering through various organs and tissues of the body [2].

Most studies on VLM-specific immune responses have reported on Toxocara canis larva infection. In human toxocariasis, elevation of T-helper type-2 (Th2) cell-related cytokine production has been reported [3,4]. In mice, various cytokines were produced during toxocariasis. Those included Th2 cytokines (IL-4 and IL-5), Th1 cytokines (IFN-γ, IL-12, and TNF-α), and regulatory T (T_reg) cell related cytokines (IL-10 and TGF-β), which were expressed during experimental toxocariasis in mice [5,6]. However, in most investigations, a specific time point was used, and alteration of immune responses using serial time points has not been investigated. In addition, there are a few studies about immune responses against VLM cause by Toxascaris leonina. In this study, to determine alteration of immune responses during VLM caused by T. leonina at several time points, we experimentally infected mice with the embryonated eggs of T. leonina and measured Th cell-related serial cytokine production after infection.

Adult T. leonina females were obtained from naturally infected dogs. Eggs were obtained from the uteri under microscopy and washed 6 times with sterile PBS. After collection, in order to prevent contamination with bacteria, the eggs were thoroughly and carefully washed several times over a 3-hr period in PBS containing antibiotics. The eggs were then incubated at 25℃ until they contained embryonated larva (second stage larva). C57BL/10 female mice, 6 weeks of age, were purchased from Samtako Co. (Suwon, Gyeonggi-do, Korea). Total 25 mice (5 per each group) were orally infected with a single dose of 500 embryonated T. leonina eggs. The mice were sacrificed on days 5, 14, 28, and 42 post-infection (PI), and sera and various organs (brain, heart, intestine, liver, lung, muscle, and spleen) were obtained from mice at each time point. Sera were stored at -20℃ before use. Each organ was weighed and digested in artificial digestive juice (0.2% pepsin, pH 2.0) at 37℃ during a period of 4 hr, and the number of released larvae was counted. In addition, lung tissues were fixed in 10% neutral-buffered formalin and embedded in paraffin blocks. Transverse sections (5 µm) of each organ tissue were stained with hematoxylin and eosin (H&E) and PAS. All animal studies were approved by the Pusan National University Animal Care and Use Committee.

Total RNA was extracted from the brain, heart, intestine, liver, lung, muscle, and spleen in infected (on 14 days PI) and uninfected mice using 1 ml of QIAzol (Qiagen Science, Valencia, California, USA). The RNA extraction was performed in accordance with the manufacturer's protocols. The CCL11 (eotaxin for eosinophil recruitment), thymus, and activation-regulated chemokine thymic stromal lymphopoietin (TSLP for Th2 cell activation) and CXCL1 (Gro-α for neutrophil recruitment). RNA levels were determined via real-time PCR using iCyclerTM (Bio-Rad, Richmond, California, USA) real-time PCR machines. GAPDH was utilized as the reference gene. The primer sequences were designed as described previously [7]. To investigate changes in the cytokine level by T. leonina larvae experimental infection, the culture supernatants of splenocytes were measured for determination of IFN-γ (Th1 cytokine), IL-4, IL-5 (Th2 cytokines), IL-6, IL-17A (Th17 cytokines), IL-10, and TGF-β (regulatory T-cell cytokines) levels using an ELISA kit (eBioscience, San Diego, California, USA). The splenocytes were isolated according to the previous reports [8]. The splenocytes were plated in 48-well plates at 5×10⁶ cells/ml in RPMI 1640 with 10% fetal bovine serum (FBS) and penicillin/streptomycin. For CD3 stimulation experiments, 0.5 µg/ml CD3 antibody (eBioscience) was added to cell-plated wells. The plated cells were incubated for 72 hr at 37℃ containing 5% CO₂. After incubation, the culture media was harvested and stored at -20℃. ELISA was performed 3 times. The assay was performed according to the manufacturer's recommended protocols (eBioscience). The mean±SD was calculated from data collected from individual mice. The Student's t-test or ANOVA was used for determination of significant differences. Statistical analysis was performed using the GraphPad Prism 4.0 software.

T. leonina larvae were found in various organs; their distribution differed according to the infection period. The number of larvae per gram of tissues in various organs is shown in Table 1. At day 5 PI, most larvae were detected from the lungs, spleen, intestine, and muscle. Although, T. leonina larvae were isolated from most organs at week 2 PI, the number of larvae in organs was lower than those in infected organs at day 5 PI. However, the number of larvae in the lungs at day 14 PI was not reduced from the one at day 5 PI. These results suggested that the lung is the organ most easily infected by T. leonina larvae. The airway tract was infiltrated with immune cells, and goblet cells showed greater proliferation than those of control mice. Mucus production in the lungs was enhanced after infection with T. leonina larvae (Fig. 1). After day 28 PI, the number of larvae in the muscle increased, compared to those in infected organs at days 5 and 14 PI. However, we did not find any larvae in any organ after day 42 PI. Although T. leonina infection in dogs and cats, as well as T. canis and T. cati, has been frequently reported to date [9,10], few cases of VLM due to T. leonina in other hosts have been reported. According to Prokopic and Figallova [11], who studied migration of T. leonina larvae in white mice, larvae were found in lungs of 96% of infected mice at days 4-135, and also in genital organs (84%), intestinal mucosa (81%), and skeletal muscles (100%) at day 10 PI. In this study, although larvae were found in various organs, including the brain, we did not find any larvae at day 42 PI, which differed from other studies. Perhaps T. leonina larvae infection and the survival rates might be different according to mouse strains.

Table 1.

Number of Toxascaris leonina larvae per gram of various mouse organs after infection

Fig. 1

Representative pathological changes in the lung of mice infected with T. leonina on day 14 PI. Pathological changes were observed in T. leonina infected mice (B, D), compared with non-infected mice (A, C). After histological processing, sections of the lung tissue were stained with H-E (A, B) and PAS stain (B, D). Bar=100 µm.

In order to determine whether several chemokine gene expression increased by T. leonina larvae infection, we evaluated the gene expression levels of CXCL1, CCL11, and TSLP in organs at day 14 PI. Expression of TSLP, an IL-7-like cytokine, is associated with skin or epithelial cells. In parasite infections, TSLP, known as an alarmin cytokine, along with IL-25 and IL-33, induces rapid initiation of Th2 responses [12]. In addition, Th2 cells preferentially express several receptors, including CCR3 (receptor of CCL11, CCL13, and CCL28), CCR4 (receptor of TARC and MDC), and CCR8 (receptor of CCL1), and active chemokines on these receptors are increased in inflammation, making them attractive candidates for mediation of Th2 cell-specific recruitment [13,14]. Expression of TSLP and CCL11 showed a significant increase (3- to>6-fold) in most internal organs, except the intestine at day 14 PI. However, expression of the CXCL1 gene was most highly enhanced (over 9-fold) in the intestine (Fig. 2). At that time, we found that most larvae migrate to other organs from the intestine (Table 1). These results suggested that T. leonina larva and/or their products stimulated tissue epithelial cells and/or dendritic cells to express chemokines for activation and differentiation of Th2 cells.

Fig. 2

Chemokine gene expression of T. leonina infected mouse organs at day 14 PI. After sacrifice, RNA was extracted from 1 g of each organ tissue from infected and uninfected mice. The expression level was compared with that of the GAPDH gene (^*P<0.05, ^**P<0.01, ^***P<0.001, compared with controls, in 3 independent experiments).

In order to determine host immune responses against T. leonina infection, Th1 (IFN-γ), Th2 (IL-4 and IL-5), Th17 (IL-6 and IL-17), and T_reg cell (IL-10 and TGF-β) related cytokine production in supernatants from CD3 stimulated splenocytes was evaluated at several time points after infection (Fig. 3). The levels of IFN-γ showed a graduate increase after infection and reached a peak at day 28 PI. Th2-related cytokine levels showed an increase after infection; in particular, IL-5 was significantly increased at day 14 PI and then decreased at day 28 PI. IL-6 levels showed a gradual increase until day 42 PI. In addition, IL-17A levels showed a significant and continual increase until day 42 PI. Of particular interest was that IL-10 levels were increased as early as day 5 PI, whereas TGF-β levels were slightly decreased at day 14 PI and then showed a rapid increase on day 28 PI. Although some studies on the immune responses of the host against VLM have demonstrated VLM due to T. leonina in mice by experimental infection, they did not show any specific immune responses [15]. Th17 is a pro-inflammatory Th cell subset, which plays important roles in the host defense and is involved in various autoimmune and inflammatory diseases, mainly by secretion of IL-17A and other cytokines, like IL-21 and IL-22 [16]. Th17 cells are induced from naive CD4⁺ T cells, mainly by IL-6 and TGF-β [17]. Recent studies suggested that Th17 responses against nematode infection should be one of the most important host protective mechanisms [18-20]. Although we do not know the exact role of Th17 cells in T. leonina larval infection, Th17 cells might be involved in induction of immune cell recruitment in order to kill the larvae. CXCL1 was highly expressed in the tissue of infected mice (Fig. 2). CXCL1 is one of the main chemokines expressed by eosinophils. Eosinophils were found to constitutively express receptors for IL-17A, IL-17F, and IL-23 (Th17 cytokines). IL-17A, IL-17F, and IL-23 could induce release of chemokines CXCL1, IL-8/CXCL8, and MIP-1beta/CCL4 from eosinophils [21]. These results suggested that eosinophils, neutrophils, and Th17 cells might be important in development of protective mechanisms against T. leonina larvae infection. In order to demonstrate this hypothesis, we need more information about the role of Th17 cells in infected tissues.

Fig. 3

Production of cytokines in splenocytes of T. leonina infected mice. Wells were incubated with 0.5 µg/ml (final concentration) of anti-CD3 antibody for 16 hr at 4℃, and splenocytes were added to the well, and incubated for 3 days. After activation, the levels of cytokines were measured in the supernatant using ELISA kits (^*P<0.05, ^**P<0.01, ^***P<0.001, compared with controls, in 3 independent experiments).

IL-10, which is referred to as the cytokine synthesis inhibitory factor, is an anti-inflammatory cytokine capable of inhibiting synthesis of proinflammatory cytokines [22]. Helminth parasites stimulate production of immunoregulatory mediators, which likely perform a function in the maintenance of the chronicity of infection, without any marked induction of pathology. IL-10 was generated principally by CD4⁺CD25⁺Foxp3⁺ T (T_reg) cells, and IL-10 induced differentiation of T_reg cells [23]. Although T. leonina larvae infection also induced production of IL-10 and TGF-β in this study (Fig. 3), we did not check alteration of the T_reg cell population.

In conclusion, we demonstrated that T. leonina larva first activated Th2-related chemokine gene expression and cytokine production. Then, the larvae activated Th1- and Th17-related chemokine gene expression and cytokine production. Since there were no larvae detected in tissues on day 42 PI, Th1 and Th17 immune responses might be as important as Th2 responses in T. leonina VLM.
