Molecular weight of major component proteins in crude saline extract of adult Paragonimus westermani
Y Kong,WB Kim,SY Kang and SY Cho
Department of Parasitology, College of Medicine, Chung-Ang University, Seoul 156-756, Korea.
Abstract
When the component proteins in crude saline extract of 13-week old adult Paragonimus westermani were observed by non-denaturing discontinuous-polyacrylamide gel electrophoresis (Disc-PAGE), 8 distinct bands were clearly recognized. Molecular weight (MW) of each band protein, numbered in sequence from cathodal side which appeared in 10% separating gel, was measured first by Ferguson plot utilizing different gel concentrations from 10% to 4.5%. MW of band 1 protein (known as egg protein) was 440 kDa. And MW of other band proteins were: 386 kDa in band 2, 17.4 kDa in band 3, 17 kDa in band 4, 14.3 kDa in band 5, 46 kDa in band 6, 38 kDa in band 7 and 23 kDa in band 8. When the proteins in the crude extract were separated into fractions by molecular sieve chromatography through 1.6(φ) × 70 cm sized Sephacryl S-300 Superfine column and revisualized by Disc-PAGE in 8% gel, the sequence of eluted proteins was band 1, band 2, band 6, band 7 and bands 3, 4, 5 and 8. This elution profile confirmed MW of each band protein in the crude extract as measured by Ferguson plot.
Figures
Fig. 1 Separation of component proteins in crude saline extract of adult P. westermani at different gel concentrations in Disc-PAGE. A: 10% separationg gel, B: 9% gel, C: 8% gel, D: 7% gel, E: 6% gel, F: 5.5% gel, G:5% gel and H: 4.5% gel. Protein bands were numbered as appeared from cathodal side in 10% separation gel.
Fig. 2 Calculation of minus slope of 100·log(Rƒ·100) against % gel concentration of each protein band in the saline extract of P. westermani. Numericals stand form the band number in Fig. 1.
Fig. 3 Calibration of molecular weight of the component proteins in the crude saline extract from the minus slopes. Numericals mean the band number in Fig. 1.
Fig. 4 Elution profile of crude extract of P. westermani. filtrated through Sephacryl S-300 Superfine. Eluent: 0.15M PBS containing 0.01% merthiolate and 0.006% PMSF. Flow rate: 15ml·cm-2·hr. Collection volume: 35 drops/tube.
Fig. 5 Banding patterns of each fraction collected by Sephacryl S-300 Superfine. Proteins in each fraction wee revisualized in 8% Disc-PAGE. C: Crude saline extract, 1: Fraction 1, 2:Fraction 2, 3: Fraction 3, 4: Fraction 4, 5: Fraction 5, 6: Fraction 6.
References
1.
Biguet J, et al. Rev Immunol 1965;29:5–30.
2.
Cho SY, Hong ST, Rho YH, Choi SY, Han YC. Application of micro-ELISA in serodiagnosis of Human paragonimiasis. Korean J Parasitol 1981;19(2):151–156.
3.
Cho SY, Lee DK, Kang SY, Kim SI. [An Epidemiological Study Of Human Paragonimiasis By Means Of Micro-ELISA]. Korean J Parasitol 1983;21(2):246–256.
4.
Choi WY, Yoo JE, Nam HW, Choi HR. [Purification of antigenic proteins of Paragonimus westermani and their applicability to experimental cat paragonimiasis]. Korean J Parasitol 1986;24(2):177–186.
5.
Davis BJ. Disc Electrophoresis. II. Method And Application To Human Serum Proteins. Ann N Y Acad Sci 1964;121:404–427.
6.
Hedrick JL, Smith AJ. Size and charge isomer separation and estimation of molecular weights of proteins by disc gel electrophoresis. Arch Biochem Biophys 1968;126(1):155–164.
7.
Huer B, Kim SI, Kang SY, Cho SY. Electrophoretic patterns of proteins from Paragonimus westermani in early developmental stages. Korean J Parasitol 1985;23(2):189–196.
8.
Imai J. Evaluation of ELISA for the diagnosis of paragonimiasis westermani. Trans R Soc Trop Med Hyg 1987;81(1):3–6.
9.
Imai J, et al. Jpn J Parasitol 1988;37:398–404.
10.
Joo KH, Ahn H, Chung MS, Rim HJ. Demonstration of species-specific and cross reactive components of Paragonimus westermani crude worm antigen by EITB. Korean J Parasitol 1989;27(1):9–14.
11.
Kim DC, et al. Rep, NIH Korea 1983;19:109–114.
12.
Kim SH, Kong Y, Kim SI, Kang SY, Cho SY. Immunoblot observation of antigenic protein fractions in Paragonimus westermani reacting with human patients sera. Korean J Parasitol 1988;26(4):239–243.
13.
Kim SI, Ko EK, Kang SY, Cho SY. [Antigenicity of the soluble egg antigen of Paragonimus westermani]. Korean J Parasitol 1986;24(1):49–54.
14.
Knobloch J, Lederer I. Immunodiagnosis of human paragonimiasis by an enzyme immunoassay. Tropenmed Parasitol 1983;34(1):21–23.
15.
Kojima S, et al. Jpn J Parasitol 1983;32:413–418.
16.
Lovry OH, et al. J Biol Chem 1951;193:365–375.
17.
Sadun EH, Walton BC, Buck AA, Lee BK. The use of purified antigens in the diagnosis of clonorchiasis sinensis by means of intradermal and complement fixation tests. J Parasitol 1959;45(2):129–134.
18.
Slemenda SB, Maddison SE, Jong EC, Moore DD. Diagnosis of paragonimiasis by immunoblot. Am J Trop Med Hyg 1988;39(5):469–471.
19.
Song CY, Dresden MH. Partial purification and characterization of cysteine proteinases from various developmental stages of Paragonimus westermani. Comp Biochem Physiol B 1990;95(3):473–476.
20.
Sugiyama H, Sugimoto M, Akasaka K, Horiuchi T, Tomimura T, Kozaki S. Characterization and localization of Paragonimus westermani antigen stimulating antibody formation in both the infected cat and rat. J Parasitol 1987;73(2):363–367.
21.
Yamakami K, Hamajima F. Purification of a neutral thiol protease from Paragonimus westermani metacercariae by single-step chromatography and preparation of antibodies. Int J Parasitol 1989;19(1):9–12.
22.
Yokogawa M, et al. Jpn J Parasitol 1983;32:317–322.
23.
Yoshimura K. Paragonimus westermani, P. ohirai, and P. miyazakii: electrophoretic comparison of whole body proteins. Exp Parasitol 1969;25(1):118–130.
