We performed this study to observe size difference in scanning electron micrographs between trichomonads grown for more than a year (called "old T") and T. vaginalis (called "fresh T") freshly isolated from cases of vaginitis. In addition, we compared the size of T. vaginalis (called "schematic T") obtained from schematic drawings in parasitology and related books with those of old T and fresh T. Finally, we suggested the dimensions of T. vaginalis as measured by scanning electron microscopy in this study.

A total of 7 T. vaginalis isolates were used. Isolates KT4, KT9, and KT-Kim were collected from Koreans with vaginitis, and isolate 50148 was purchased from ATCC (Manassas, Virginia, USA). These 4 isolates had been cultured for more than a year in TYM (trypticase-yeast extract-maltose, pH 6.2) medium. In addition, 3 isolates of T. vaginalis were freshly obtained from women with vaginitis; they were prepared for scanning electron microscopy (SEM) immediately after they were collected. SEM was used to detect any superficial morphological differences between the trichomonads cultured for more than a year and the freshly isolated trophozoites. T. vaginalis isolates were fixed in 3% glutaraldehyde in 0.13 M Millonig's phosphate buffer (0.13 M NaH₂PO₄, 0.1 M NaOH, pH 7.3) at 4℃. They were then washed 3 times with PBS, allowed to adhere to poly-L-lysine-coated glass coverslips, post-fixed for 1.5 hr at room temperature in 1% OsO₄ in Millonig's phosphate buffer, dehydrated in ethanols, dried in a critical point dryer, and mounted on stubs. They were then coated with gold using an ion sputtering coater, and observed with a scanning electron microscope (S-2380N, Hitachi, Tokyo, Japan) at an accelerating voltage of 25 kV. Fifteen trophozoites from the 4 isolates grown for more than a year and 27 trichomonads from the 3 fresh isolates were observed and measured. The size of the external (superficial) organelles of each trophozoite, namely length and width of body, length of the 4 anterior flagella, distance of axostyle protrusion from the end of the body, was measured. In addition, we measured the length of body, flagella, and axostyle in schematic drawings of T. vaginalis (called "schematic T") in 7 parasitology and related textbooks [5-11]. The ratios of flagella, body width, and axostyle length to body length were measured and compared with those of old T and fresh T.

The body length and width of fresh trichomonads (average L×W; 8.5×5.7 µm) were less than those of old trichomonads (9.5×6.8 µm). However, their ratios of width to length (68.6% in fresh T vs 71.9% in old T) were similar. Flagella were slightly shorter (average 10.5 µm) in fresh samples than in old ones (average 11.5 µm), and the ratio of flagellar length to body length was lower (107.4%) in the former than the latter (123.5%). Axostyle length differed the most between fresh T (average 8.2 µm) and old T (average 4.0 µm). When axostyle length was calculated as a percentage of body length, fresh trophozoites had significantly higher ratios (100.9%) than old trichomonads (40.5%) (Fig. 1). The total length including body, flagella, and axostyle was almost the same in the 2 groups (fresh T; 26.3 µm vs old T; 26.0 µm). The ratio of the length of undulating membrane (UM) to body length in old trichomonads was 72.1%, and it was difficult to observe the undulating membrane in freshly isolated trophozoites. Therefore, the ratio of UMs could not be measured.

The ratio of body width to body length in the schematic trichomonads was 64.8%, lower than those of fresh trichomonads (68.6%) and old trophozoites (71.9%). The ratios of axostyle and flagella to body length in the schematic T were also lower than in the fresh and old T. A significant difference was also seen in the ratio of axostyle to body length in schematic T (30.4%) and fresh T (100.9%), and the ratio for the flagella of schematic T (90.9%) was significantly lower than that for old T (123.5%). The undulating membrane in the schematic T (ratio 53.5%) extended only about a half of the length of the body, compared with 72.1% in old T (Table 1).

The axostyle of T. vaginalis runs from the anterior towards the posterior end of the cell. It forms the capitulum in the anterior portion and a narrow tube in the posterior [12]. It may have 2 functions in trichomonads; 1) it may be a supportive entity, 2) it may participate in the cell division process, causing constriction of the nucleus during karyokinesis [13]. Although the axostyles of fresh T were twice as long as those of old T, it is hard to determine the specific role of the longer axostyles in the fresh T; the fresh T need to overcome the flushing effects of the normal fluid secretion of the vagina in order to survive. In those conditions, the axostyle may have to be strong to fulfill a supportive role. Honigberg and Brugerolle [4] suggested that the shape of cells grown in culture tends to be more uniform than that of those in vaginal secretions. Consistent with this, we found that old T varied less in length than fresh T.

It is known that trichomonads tend to increase in size under certain, usually unfavorable, condition. Old T was about 1 µm longer and wider than fresh T, although their ratios of width to length were similar. This difference was in accordance with previous reports in which the culture medium probably affected the size of trichomonads [2,3,14].

Since the ratio of the length of the UM to that of the body has often been considered an important parameter distinguishing the 3 species of human-infecting Trichomonas [15], the UM extends about 2/3 of the length of the cell in Trichomonas tenax; and about 1/3 the length of the cell in T. vaginalis, while in Trichomonas hominis, it extends the whole length of the body [9]. However, the ratio (in percent) of the length of the UM to that of the body in T. vaginalis was 62.1±10.3% based on data in Table III of Honigberg and King [16]. In the present study, old T (72.1±10.5%) had significantly longer UM extension ratios than those of the schematic T as given in several parasitology textbooks (53.5±11.4%). The UM of fresh T, however, could not be measured because of the presence of apparent pseudopodial extension of the cytoplasm, especially on the side of the UM. Therefore, we suggest that the UM of T. vaginalis extends about 3/4 of the length of the body.

Measurements of the total length of T. vaginalis should include the body length, flagellar length, and axostyle length. The detailed reports of the structure of T. vaginalis by Honigberg and Brugerolle [4] and Benchimol [13] did not mention the total length, whereas several parasitology textbooks quoted a wide range of size (7-32 µm in length) [5-11]. Fresh and old trichomonads in the present study had almost the same average length (about 26 µm). Hence, it needs to present the size of T. vaginalis with some approximation to real trophozoites. In summary, we suggest that the total length of T. vaginalis (including the body length, flagellar length, and axostyle length) averages about 26 (21-32) µm, its body measures 9.5 (7.4-11.4)×6.8 (5.3-7.7) µm, and its undulating membrane extends 3/4 of its body length.
