Developmental surface ultrastructure of Macroorchis spinulosus in albino rats
| Home | E-Submission | Sitemap | Contact us |
top_img
Korean J Parasito Search

CLOSE

Korean J Parasito > Volume 42(4):2004 > Article
Hong, Woo, and Kwon: Developmental surface ultrastructure of Macroorchis spinulosus in albino rats

Abstract

Developmental surface ultrastructure of Macroorchis spinulosus was studied by scanning electron microscopy. One-day-old juvenile fluke was leaf-shaped and bent ventrally. Body surface was covered densely with peg-like spines and with cobblestone-like cytoplasmic processes. Ciliated sensory papillae were concentrated around oral sucker. Several unciliated sensory papillae occurred equidistantly on oral sucker and acetabulum. The ciliated papillae appeared in two longitudinal lines symmetric bilaterally on dorsal surface. On adult flukes, tegumantal spines became wider in middle of the body surface. The cytoplasmic processes differentiated into more fine velvety form. It is likely that the differentiated fine cytoplasmic processes are an increased absorptive surface to adult M. spinulosus. It is suggested that single pointed tegumental spines on anterior half of the body may be supportive for this fluke to migration.

INTRODUCTION

Macroorchis spinulosus is a minute intestinal trematode of the family Nanophyetidae, which is represented by large testes. Adult M. spinulosus were collected from the small intestine of mammals, infected naturally or experimentally, such as dogs, cats, mice, guinea pigs, rabbits, and albino and house rats (Ando, 1918). The metacercariae of M. spinulosus were found from crustacean intermediate hosts such as freshwater crabs, Potamon dehaani and P. obtusipes (Ando, 1918, 1921) and crayfish, Cambaroides similis (Chai et al., 1996). In recognition of one or more morphological differences, distinctive intermediate hosts and geographical segregation, new species of the genus Macroorchis, M. himizu, M. chimarrogalus and M. elongates, were proposed (Machida and Uchida, 1982; Saito et al., 1982). Recently, the morphological features of M. spinulosus were found different from the original descriptions and supplemented and redescribed in detail based on adult morphologies (Chai et al., 1996).
Information on surface ultrastructures of the growth and development of M. spinulosus in the final hosts is scarce. It is reported that the excysted metacercariae of M. spinulosus grow up rapidly to ovigerous adult flukes in the small intestine of final hosts (Woo et al., 2003). This work was carried out to get more information on developmental surface ultrastructures of M. spinulosus in the final host, and may provide knowledge on functions of the differentiated tegument in host-parasite interactions.

MATERIALS AND METHODS

The crayfish, Cambaroides similis, were caught in the streams in Macheon-myon, Hamyang-gun, Gyeongsangnam-do, Korea from October to December 1993. The crayfish were crushed with a mortar and a pestle, and washed with PBS. The M. spinulosus metacercariae were collected from the sediment under a dissecting microscope. Albino rats, Charles River Sprague-Dawley strain, 4-week-old, were fed each with 100 metacercariae.
The Rats were sacrificed at predetermined intervals, 1, 3, 5, 7, 14, and 28 days after the infection. The rats' intestine was resected out and divided into duodenum, jejunum and ileum. Intestinal contents were washed in PBS and M. spinulosus were recovered from the sediments under a dissecting microscope. The recovered flukes were washed with cold physiological saline 3 times and fixed in cold 2.5% glutaraldehyde (0.1 M phosphate buffer, pH 7.2) at 4℃. After washing with buffer, flukes were post-fixed in 1% osmium tetroxide (0.1 M phosphate buffer, pH 7.2) for 1 hr. The fixed flukes were dehydrated through a graded series of ethanol, exchanged with acetone, and critical point-dried. The dried flukes were mounted on metal stubs and coated with gold in an ion sputtering coater. The prepared fluke specimens were observed with a scanning electron microscope (ISI DS-130C, ISI Co., Tokyo, Japan) at an accelerating voltage of 10 kV.

RESULTS

Juvenile flukes

The body of 1-day-old fluke was flat and leaf-shape pointed posteriorly. The oral sucker, circular and wide open, was subterminal at anterior end of the body. The acetabulum was median at anterior two-fifths of the body (Fig. 1A). The lip of oral sucker appeared velvety and wrinkled cytoplasmic processes, and was devoid of tegumental spines. Unciliated sensory papillae swelled with wrinkled surface (Type II papillae), 14 in number, located equidistantly on the lip of oral sucker. Sensory papillae bulbous with the tegument wrinkled at base and smooth at apex and with a short cilium (Type I papillae) ornamented densely around the oral sucker and sparsely over the body surface. The Type I papillae were found on inner surface of the oral sucker. Anterior apex was devoid of tegumental spines and appeared cytoplasmic processes corrugated. On anterior outskirts of the oral sucker Type I papillae intercalated Type II papillae, looks supplementing the later ones (Fig. 1B). Surface of the acetabulum was covered with worm-like cytoplasmic processes arranged radially. The acetabulum was encircled with two circles, inner and outer, of Type II papillae. Of the outer circle, six Type II papillae located equidistantly along outer margin of the acetabulum. Of inner circle, 5-6 Type II papillae sat on anterior two-thirds of the lip (Fig. 1C). Type I papillae, 3-5 in number, were found on lateral rim of the acetabulum. Genital pore opened distantly postero-median to the acetabulum, revealing general feature of the ventral surface. On dorsal surface, Type I papillae aligned bilaterally symmetrical (Fig. 1D) and became more distant posteriorly.
The body surface, from anterior to posterior ends, was beset with tegumental spines, spade-like anteriorly and peg-like posteriorly (Figs. 1E, 1F). The tegumental spines were deployed concentric to the oral sucker on anterior half of the body. Posterior end of the body notched in V-shape with an excretory pore. Cytoplasmic processes was cobblestone-like on anterior half of the body and became slightly finer posteriorly (Figs. 1E, 1F).
In 3-day-old flukes, cytoplasmic processes on anterior apex devoid of tegumental spine were velvety. On the body surface, the cytoplasmic processes differentiated into transient shapes from cobblestones to velvet between tegumental spines.

Adult flukes

In 5-day-old flukes, the body got thicker and paremchymatous, and bulged out like a hip in posterior half. From half of the observed flukes, sperms ejaculated from the genital pore found on the ventral surface. Type I papillae concentrated on the anterior apex while very rare all over the body surface. On margin of the oral sucker, two grouped form of 2-3 Type I papillae located bilaterally symmetrically. Type II papillae got prominent contour on the lip of oral sucker (Fig. 2A). The acetabulum became thinner and less stout compared to the oral sucker. One grouped form of two Type I papillae was found anterior margin of the acetabulum. Genital opening revealed protruded as a mound devoid of tegumental spines, posterior to the acetabulum (Fig. 2B). Excretory pore, extruded buttock-like, with spine-free Y-shape area on posterior end of ventral surface. Around the excretory pore sensory papillae were not found. Tegumental spines on posterior half of the body retained its peg-like shape and density. Cytoplasmic processes were differentiated into velvety ones on the entire body surface.
In 7-day-old flukes, the surface structure retained generally as in the 5-day-old flukes. Anterior body armored heavily with tegumental spines and reduced loosely to the end of body. Tegumental spines got bigger and stouter than those of juvenile flukes. The spines revealed spade-shape with broader base on anterior body surface (Fig. 2C) and narrowed posteriorly to peg-like ones with a pointed-tip (Fig. 2D). The tegumental spines on the middle part of the ventrolateral surface of the body were wider than those on the dorsal surface. Cytoplasmic processes developed into fine velvety processes over the body surface (Figs. 2C, 2D). The swollen dome of Type II papillae, on the oral sucker and acetabulum, appeared strawberry-like covered with fine velvety cytoplasmic processes (Fig. 2C). Type I papillae elevated with spiraling tegument or with concentric circles; looked like a fried egg at top view (Figs. 2C, 2D).
In 14-day-old flukes, maximum width of the body was observed at posterior one-third level, just after the acetabulum. Whole surface featured similar to that of 7-day-old flukes. Posterior end of the body protruded out like a turret, centered with an excretory pore. Around the excretory pore was free from tegumental spines. At central part of the lip of oral sucker was spaced devoid of sensory papillae and tegumental spine, where cytoplasmic processes were wrinkled longitudinally. On anterior margin, transient to the apex, of the oral sucker, 3-4 Type I papillae intercalated the Type II papillae. On anterior surface, ventral and dorsal, of the body, some Type I papillae emerged very close, so seemed to form a grouped form.
In 28-day-old flukes, whole surface retained ultrastructure similar to that of 14-day-old flukes. The tegumental spines on posterior half of the body were decreased in their size and density. The acetabulum was wrinkled radially and equal size to the oral sucker. One Type II papilla on anterior center of outer circle flanked a Type I papilla. On the body surface, Type I papillae were most prominent observed yet, and aligned symmetrical bilaterally (Fig. 2E). Of the type I papillae, smooth dome based on 2-3 encircling rings supported with velvety cytoplasmic processes of adjacent surface. On the posteriormost surface, the tegumental spines reduced to minute in size and sparse in density. The cytoplasmic processes were finer on posterior surface by 1/2-1/3 than those on anterior surface of the body (Fig. 2F).

DISCUSSION

The cytoplasmic processes of M. spinulosus were cobblestone-like in juvenile flukes and differentiated into velvety ones in adult flukes. This developmental differentiation of cytoplasmic processes has been reported from intestinal and heterophyid trematodes. It has been considered for adult flukes that fine velvety cytoplasmic processes covering posterior half of the body is an efficient way of increasing absorptive area to provide increased nutritional demand of reproductive organs producing a large quantity of eggs (Køie, 1987; Hong et al., 1991). A reduction of width and density of the tegumental spines in posterior half of the body enhanced the increasing of absorptive surface area of M. spinulosus as in other flukes.
The peg-like single tipped tegumental spines on anterior surface of M. spinulosus retained their shape and density throughout developmental stages. In albino rats, a final host, M. spinulosus revealed habitat shift. It resided in the jejunum in juvenile stage and migrated up and established at duodenum as grew up to adult stages (Woo et al., 2003). The tegumental spines with a pointed tip may supportive for locomotion of juvenile flukes moving from one habitat to another. It is suggested from Centrocestus armatus, Metagonimus yokogawai and Neodiplostomum seoulense that less pointed tips on the juvenile flukes work more effectively for their locomotion and anchorage (Woo et al., 1998; Lee et al., 1984, 1985). Compared with single tipped spines, tegumental spines of heterophyid flukes, such as M. yokogawai and Heterophyopsis continua, increased pointed tips as growing up to adults (Lee et al., 1984; Hong et al., 1991). It was suggested that the scale-like multi-pointed tegumental spines on the anterior half surface of the body could function as an abrasive apparatus producing debris for feeding from the intestinal mucosa rather than as a locomotive apparatus (Hong et al., 1991).
Ciliated sensory papillae with a short or long cilium have been found in diverse species of trematodes (Fujino et al., 1979; Page et al., 1980). The cilium is extended through the tegument and connected to nerve fibers, so that it may sense contacts and changes encountered from environments and transmit those signals to the central nervous system. The ciliated (Type I) sensory papilla was suggested to function as tango-, rheo-, mechano-, or chemoreceptor (Lee et al., 1984; Ip and Desser, 1984; Smales and Blankespoor, 1984). In M. spinulosus, Type I papillae were concentrated around the oral sucker and increased in number as it grew up to adult fluke. The oral sucker was larger than the acetabulum in juvenile stage, but the two suckers became almost equal size in adult stage (Woo et al., 2003). The enlarged acetbulum could holdfast the matured ovigerous fluke to the intestinal mucosa and render the oral sucker to probe actively its environs for feeding (Hong et al., 1991). The Type I papillae abundant around the oral sucker are supposed to sense contacts to intestinal mucosa, flow of intestinal contents and nutrient composition (Morris and Threadgold, 1967).
Unciliated sensory papillae, similar to the Type II papillae of M. spinulosus, have been found on the oral sucker and acetabulum of several species of flukes such as H. continua, M. yokogawai, N. seoulense, Clonorchis sinensis, Echinostoma hortense and C. armatus (Fujino et al., 1979; Lee et al., 1984, 1985, 1986; Hong et al., 1991; Woo et al., 2003). Unciliated domed sensory papillae are covered with tightly packed tegument and have a bulbous extension containing a large amount of electron-dense materials (Hoole and Mitchell, 1981). From anatomical structural features, this type of sensory papillae has been suggested to be tango- and mechanoreceptive. In M. spinulosus, the oral sucker and acetabulum appeared equipped with equal number of the Type II papillae from juvenile to adult stages. Being considered with dimensions of ovigerous adult flukes, the two sucking organs of M. spinulosus may exert almost equal suctorial power upon the intestinal musoca.
On dorsal surface of M. spinulosus, the Type I papillae appeared arranged in linear symmetry, which found similar to those of the ciliated papillae of H. continua and M. yokogawai (Lee et al., 1984; Hong et al., 1991). It is suggested that the Type I papillae sense contacts and pressure of dorsal surface to the intestinal mucosa.

Notes

This work was supported by the Research Grant from Chung-Ang University in 2003.

REFERENCES

1. Ando A. On a new trematode with the fresh water crab as its intermediate host. Tokyo Iji Shinshi 1918;2079:10-17 (in Japanese).

2. Ando A. A contribution to the study of a new trematode, Macroorchis spinulosus n. g., n. sp., whose intermediate host is the crab. Nippon Biseibutsu Gakkai Zasshi 1921;15:813-826 (in Japanese).

3. Chai JY, Sohn WM, Huh S, Choi MH, Lee SH. Redescription of Macroorchis spinulosus Ando, 1918 (Digenea: Nanophyetidae) encysted in the fresh water crayfish, Cambaroides similis. Korean J Parasitol 1996;34:1-6. PMID: 8820735.
crossref pmid
4. Fujino T, Ishii Y, Choi DW. Surface ultrastructure of the tegument of Clonorchis sinensis newly excysted juveniles and adult worms. J Parasitol 1979;65:579-590. PMID: 390108.
crossref pmid
5. Hong SJ, Chai JY, Lee SH. Surface ultrastructure of the developmental stages of Heterophyopsis continua (Trematoda: Heterophyidae). J Parasitol 1991;77:613-620. PMID: 1865270.
crossref pmid
6. Hoole DH, Mitchell JB. Ultrastructural observation on the sensory papillae of juvenile and adult Gorgoderina vitelliloba (Trematoda: Gorgoderidae). Int J Parasitol 1981;11:411-417.
crossref
7. Ip HS, Desser SS. Transmission electron microscopy of the tegumentary sense organs of Cotylogaster occidentalis (Trematoda: Aspidogastrea). J Parasitol 1984;70:563-575.
crossref
8. Køie M. Scanning electron microscopy of rediae, cercariae, metacercariae and adults of Mesorchis denticulatus (Rudolphi, 1802) (Trematoda, Echinostomatidae). Parasitol Res 1987;73:50-56. PMID: 3809150.
crossref pmid
9. Lee SH, Hong SJ, Chai JY, Hong ST, Seo BS. Tegumental ultrastructures of Echinostoma hortense observed by scanning electron microscopy. Korean J Parasitol 1986;24:63-70.
crossref pmid
10. Lee SH, Hong SJ, Chai JY, Seo BS. Studies on intestinal trematodes in Korea. XV. Tegumental ultrastructures of Fibricola seoulensis according to developmental stages. Seoul J Med 1985;26:52-63.

11. Lee SH, Seo BS, Chai JY, Hong SJ. Study on Metagonimus yokogawai (Katsurada, 1912) in Korea. VII. Electron microscopic observation on the tegumental structure. Korean J Parasitol 1984;22:1-10.
crossref pmid
12. Machida M, Uchida A. Some helminth parasites of the Japanese shrew mole from the Izu Peninsula. Mem Natl Sci Mus (Tokyo) 1982;15:149-154.

13. Morris GP, Threadgold LT. A presumed sensory structure associated with the tegument of Schistosoma mansoni. J Parasitol 1967;53:537-539. PMID: 6026841.
crossref pmid
14. Page MR, Nadakavukaren MJ, Huizinga HW. Rebeiroia marini: Surface ultrastructure of redia, cercaria, and adult. Int J Parasitol 1980;10:5-12.
crossref
15. Saito Y, Watanabe T, Yamashita T. Two new intestinal trematodes, Macroorchis chimarrogalus n. sp. and Macroorchis elongatus n. sp. from Japanese water shrew and others, with a description of the metacercaria of Macroorchis chimarrogalus n. sp. (Trematoda: Nonophyetidae). Acta Med Biol 1982;30:47-56.

16. Smales LR, Blankespoor HD. Echinostoma revolutum (Froelich, 1802) Loss 1899 and Isthmiophora melis (Schrank, 1788) Luche, 1909 (Echinostomatinae, Digenea): Scanning electron microscopy of the tegumental surface. J Helminthol 1984;58:187-195.
crossref
17. Woo HC, Chai JY, Hong SJ. Recovery, growth and development of Macroorchis spinulosus in albino rats. Korean J Parasitol 2003;41:27-33. PMID: 12666727.
crossref pmid pmc
18. Woo HC, Seo MD, Hong SJ. Surface ultrastructure of juvenile and adult stages of Centrocestus armatus. J Helminthol 1998;72:215-219. PMID: 9765372.
crossref pmid
Fig. 1
Scanning electron micrographs of one-day-old Macroorchis spinulosus. A. Ventral view of a fluke. Bar = 30 µm. B. Ciliated Type I (arrow) and Type II sensory papillae around the oral sucker. Bar = 10 µm. C. Unciliated Type II sensory papillae arranged in two circles on the rim of acetabulum. Bar = 6 µm. D. Dorso-anterior surface beset densely with tegumental spines. Bar = 10 µm. E. Ventral surface between the oral sucker and acetabulum. Bar = 2 µm. F. Narrow peg-like tegumental spines on ventro-posteriormost surface. Bar = 2 µm.
Fig. 2
Scanning electron micrographs (SEM) of five-day-old (A & B), seven-day-old (C & D), and 28-day-old flukes (E & F). A. The oral sucker armed with Type I and II sensory papillae and one pair of grouped type I papillae (arrows) on both side. Bar = 10 µm. B. The genital opening posterior to the acetabulum. Bar = 10 µm. C. The ciliated Type I papillae dispersed between unciliated Type II papillae on lateral surface to the oral sucker. Bar = 4 µm. D. Ventro-posteriormost surface. Bar = 4 µm. E. Dorso-anterior surface ornamented with Type I papillae. Bar = 10 µm. F. Ventro-posteriormost surface showed velvety cytoplasmic processes and tiny tegumental spines. Bar = 5 µm.
