The first discovery of larval Gnathostoma hispidum (Nematoda: Gnathostomidae) from a snake host, Agkistrodon brevicaudus
W M Sohn,*1 and S H Lee2
1Department of Parasitology, College of Medicine, Gyeongsang National University, Chinju 660-280, Korea.
Received February 06, 1998; Accepted March 28, 1998.
Abstract
The present study was performed to observe the infection status of several kind of animals with indigenous Gnathostoma in Korea, and morphological characteristics of gnathostome larvae detected from pit-viper, Agkistrodon brevicaudus, for the species identification. To know the existence of Gnathostoma in Korea, 3,450 loaches, 24 bullfrogs, several kinds of snakes, i.e., 55 Elaphe rufodorsata, 2 Dinodon rufozonatum rufozonatum, 62 Rhabdophis tigrinus tigrinus and 87 Agkistrodon spp., and 438 cats were examined. A total of 21 larval gnathostomes was detected from 12 pit-vipers, A. brevicaudus. They were 2,233 × 0.343 mm in average size and covered with about 210 transverse rows of minute cuticular spines. Their characteristic head bulbs were provided with 4 rows of hooklets of which average numbers in each row were 36.8, 39.0, 41.7 and 44.3, posteriorly. In the cross sections of midgut level, the intestinal wall consisted of a single layer of 19-25 elongate epithelial cells with a single nucleus. SEM observation of the larvae revealed unique features of head bulb, cuticular spines on transverse striations and a cervical papilla. On the basis of above morphological characteristics, they were identified as the advanced third-stage larvae of Gnathostoma hispidum. It was first confirmed that the pit-viper, Agkistrodon brevicaudus is the snake intermediate host of G. hispidum.
Figures
Figs. 1-5 Fig. 1. An encysted larva of Gnathostoma hispidum from the muscle of a pit-viper, Agkistrodon brevicaudus. Fig. 2. The advanced third-stage larva (AdL3) of G. hispidum recovered from the muscle of a snake. Fig. 3. The AdL3 of G. hispidum recovered from the viscera of a snake. Figs. 4 & 5. Head-bulbs of the larvae bearing four transverse rows of hooklets.
Figs. 6-8 Cross sections of the AdL3 of G. hispidum collected from the pit-viper. Fig. 6. Esophagus level showing the cervical sacs (*), esophagus (E) and lateral cord (LC). Fig. 7. Midgut level showing the intestine (*) and lateral cord (LC). Fig. 8. Magnification of midgut level with a section of intestine consisted of single layer of elongate epithelial cells. Most epithelial cells possessed a single large nucleus.
Figs. 9-16 Scanning electron microscopic (SEM) view of the advanced third-stage larvae of Gnathostoma hispidum from the pit-viper, Agkistrodon brevicaudus. Fig. 9. Whole body showing a head-bulb with hooklets, about 210 rows of transverse striations with cuticular spines and a cervical papilla (encircled). Fig. 10. Subfrontal view of the head bulb. An amphid (A) and two labial papillae (LP) are seen on each lip. Fig. 11. Four transverse rows of hooklets on the head-bulb. Each hooklet somewhat curved posteriorly. Fig. 12. Magnification of the boxed area in Fig. 11. Two hooklets are seen on th 5th row (arrows). Fig. 13. Body surface of the anterior part having cuticular spines on the transverse striations and a dome -like cervical papilla located between the 11th and 12th transverse striations. Fig. 14. Magnification of a part of Fig. 13. Body surface consists of a highly wrinkled cuticle and posteriorly curved spines. Fig. 15. Body surface of the middle part of which cuticular spines are more sparsely distributedon the transverse striations. Fig. 16. Adjacent area of the anus of which surface consists of a highly wrinkled cuticle without spines.
Tables
Table 1 Results of a survey on the indigenous gnathostome in Korea
Table 2 Recovery of larval gnathostomes from the Korean vipers
Table 3 Measurementsa) of the larval gnathostome from Agkistrodon brevicaudus and comparison with those of previous authors
Table 5 Comparison of the number of hooklets on head-bulbs in four species of larval Gnathostoma (AdL3)
Table 6 Morphological differencesa) in cross at the midgut level in four species of larval Gnathostoma (AdL3)
References
1.
Akahane H, Iwata K, Miyazaki I. Studies on Gnathostoma hispidum Fedschenko, 1872 parasitic in loaches imported from China. Jpn J Parasitol 1982;31:507–516.
2.
Akahane H, et al. Morphological features of "large-type larval" Gnathostoma in loaches from mainland China. Jpn J Parasitol 1987;36:424–426.
3.
Akahane H, et al. Morphological difference in cross section of the advanced third-stage larvae of Gnathostoma spinigerum, G. hispidum and G. doloresi. Jpn J parasitol 1986;35:465–467.
4.
Ando K, et al. Gnathostoma nipponicum infection in the past human cases in Japan. Jpn J Parasitol 1991;40:184–186.
5.
Ando K, Tanaka H, Taniguchi Y, Shimizu M, Kondo K. Two human cases of gnathostomiasis and discovery of a second intermediate host of Gnathostoma nipponicum in Japan. J Parasitol 1988;74(4):623–627.
6.
Chandler AC. A contribution to the lifehistory of a gnathostomes. Parasitology 1925;17:237–244.
8.
Daengsvang S. Gnathostomiasis in Southeast Asia. Southeast Asian J Trop Med Public Health 1981;12(3):319–332.
9.
Kim CH. [The Infection Status Of Sparganum And Gnathostoma In Frogs Of Southern Part Of Korea]. Korean J Parasitol 1983;21(1):83–86.
10.
Kim YK. A study on Gnathostoma (1) An investigation into the geographical distribution of larvae on the second and third stage in Gyeongsang Nam do. Bull Pusan Nat Univ 1973;15:111–116.
11.
Koga M, et al. Morphology and experimental infections of gnathostome larvae from imported loaches, Misgurnus anguillicaudatus. Jpn J parasitol 1985;34:361–370.
12.
Kondo K, et al. Scanning electron microscopy of larvae and adult worms of Gnathostoma hispidum. Jpn J Parastitol 1984;33:577–586.
13.
Lee SH, Hong ST, Chai JY. Description of a male Gnathostoma spinigerum recovered from a Thai woman with meningoencephalitis. Korean J Parasitol 1988;26(1):33–38.
14.
Mako T. On the larval Gnathostoma doloresi found in a snake, Dinodon semicarinatus from Amami-Oshima Is., Japan. Jpn J Parasitol 1985;34:493–499.
15.
Miyazaki I. On the second stage larvae of three species of Gnathostoma occurringin Japan(Nematoda: Gnathostomidae). Acta Med 1952;22:1433–1441.
16.
Miyazaki I. On the genus Gnathostoma and human gnathostomiasis, with special reference to Japan. Exp Parasitol 1960;9:338–370.
18.
Miyazaki I, et al. On gnathostome larvae found from snakes in New Orleans, USA. Jpn J Parasitol 1959;8:351–352.
19.
Miyazaki I, et al. On a gnathostome larva encysted in the muscle of salamander, Hynobius. Acta Med(Fukuoka) 1952;22:467–473.
20.
Miyazaki I, et al. On the larval Gnathostoma doloresi Tubangui found in a snake from Ishigaki-jima, the Ryuku Island (Nematoda: Gnathostomidae). Kyushu J Med Sci 1962;13:165–169.
21.
Morita H, et al. Gnathostoma cases caused by imported loaches. J Nara Med Ass 1984;35:607–619.
22.
Nawa Y, Imai J, Ogata K, Otsuka K. The first record of a confirmed human case of Gnathostoma doloresi infection. J Parasitol 1989;75(1):166–169.
23.
k Ogata,et al. Three confirmed and five suspected human cases of G. doloresi infection found in Miyazaki Prefecture. Jpn J Parasitol 1988;37:358–364.
25.
Sohn WM, Kho WG, Lee SH. Larval Gnathostoma nipponicum found in the imported Chinese loaches. Korean J Parasitol 1993;31(4):347–352.
26.
Sohn WM, Lee SH. Identification of larval Gnathostoma obtained from imported Chinese loaches. Korean J Parasitol 1996;34(3):161–167.
27.
Tada I, et al. On the larval Gnathostoma doloresi found in snakes, Trimeresurus flavoviridis flavoviridis, from Amami-oshima Is., Kagoshima, Japan. Jpn J Parasitol 1969;18:289–293.
28.
Takakura Y, et al. Studies on experimental infection to the piglets with Gnathostoma hispidum larvae and morphology of the worms. Jpn J Parasitol 1985;34:211–218.
29.
Taniguchi Y, Ando K, Isoda K, Shimizu M, Sonobe K. Human gnathostomiasis: successful removal of Gnathostoma hispidum. Int J Dermatol 1992;31(3):175–177.
30.
Taniguchi Y, Hashimoto K, Ichikawa S, Shimizu M, Ando K, Kotani Y. Human gnathostomiasis. J Cutan Pathol 991 Apr;18(2):112–115.
31.
Toshioka S. On the larval Gnathostoma doloresi found in the himehabu, Trimeresurus okinavensis, from Amami Island, Kagoshima Prefecture, Japan. Snake 1970;2:57–58.
32.
Yamaguchi T, et al. Studies on Gnathostoma in Shikoku. Shikoku Acta Med 1956;9:316–326.
